S11 Copper Winding Three Phase Oil Immersed Transformer 20kv For Enterprise / Agriculture

Name: S11 Copper Winding Three Phase Oil Immersed Transformer 20kv For Enterprise Agriculture
Brand: HENGFENGYOU
Price: 200 USD

Wholesale S11 Copper Winding Three Phase Oil Immersed Transformer 20kv For Enterprise / Agriculture from china suppliers

Brand Name : HENGFENGYOU

Model Number : S11

Certification : ISO IEC CB COC KEMA SNI SABS CCC

Place of Origin : China

MOQ : 1

Payment Terms : LC T/T

Supply Ability : 5000 pieces/year

Delivery Time : 15 DAYS

Packaging Details : wooden case

Phase : Single or Three phase

Standard : GB1094-1996

Application : Electric

Material : Copper Winding

Usage : Electronic

Keywords : distribution power transformer

Rated voltage : 20~100 kVA

Vector group : Dyn11,Dyn5,Yyno or others

CORPORATION: : KPLC/REA/PEC

CERTIFICATION : Type test report/CESI/ CTQC

Price : 200-200000/piece

Contact Now

20kv Three-Phase Oil-Immersed Distribution Transformer (Enterprise, agriculture, civil use)

Product description

_{* Standard Features
1. Product Range:15kVA-10000kVA, up to 44kV
2. System voltage: max. 36 kVA 200 BIL
3. Oil preservation: hermetically sealed or conservator/free breathing
4. Cooling medium: mineral oil, Midel
5. Steel type core clamping system
6. High voltage (HV) multilayer winding
7. Low voltage (LV) foil winding or layer winding
8. Winding materials aluminium or copper}

kVA	Voltage		VECTOR GROUP	LOSSES		No-load Current	Weight(kg)		Overalldimension mm
	H.V. kV	L.V V	VECTOR GROUP	No-load loss	Load loss		Oil weight	Total weight		W	H
20	20 22	380 400 415 433	Yyn0 Dyn11 Yzn11	90	530	2.3	75	230	880	610	855
30				100	660	2.1	100	305	900	610	990
50				130	960	2	185	515	920	610	1150
63				150	1145	1.9	195	550	920	630	1180
80				180	1370	1.9	200	600	930	650	1200
100				200	1650	1.8	210	695	950	680	1250
125				240	1980	1.7	235	810	960	780	1270
160				280	2420	1.6	255	950	1160	710	1330
200				340	2860	1.5	280	1065	1190	730	1340
250				400	3350	1.4	300	1200	1280	820	1360
315				480	4010	1.4	320	1360	1380	910	1390
400				570	4730	1.3	370	1580	1430	950	1470
500				680	5660	1.2	400	1790	1520	1020	1510
630				810	6820	1.1	460	2100	1680	1150	1530
800				980	8250	1	495	2420	1810	1280	1580
1000				1150	11330	1	590	3080	1840		1690
1250				1360	13220	0.9	630	3460	1850	1300	1730
1600				1640	15950	0.8	710	4015	1920	1350	1790

S11 Copper Winding Three Phase Oil Immersed Transformer 20kv For Enterprise / Agriculture

Special Features:

_{1. Suitable for indoor or outdoor application
2. Air temperature: Maximum temperature: +40ºC; Minimum temperature:-30ºC
3. Humidity: Monthly average humidity 95%; Daily average humidity 90% .
4. Atitude above sea level: Maximum installation altitude: 2000m
5. Max wind speed:35M/s
6 No frequent violent shake
7. Ambient air not apparently polluted by corrosive and flammable gas, vapor etc}

S11 Copper Winding Three Phase Oil Immersed Transformer 20kv For Enterprise / Agriculture

Our Service

_{Our Service:
1. OEM is available.
2. Your inquiry related to our product & price will be replied within 24 hours
3. Well-trained & experienced staff are to answer all your inquiries in English
4. Working time: 8:00am ~17:45pm, Monday to Saturday. (UTC+8)
5. Customized solution & perfect after-sale service
6. Payment: we can accept T/T, L/C, Western Union.
7. For large order, engineer can be sent to your country for on-site mainternace instructions.}

Product Tags:

three phase oil immersed transformer

oil immersed distribution transformer

S11 Copper Winding Three Phase Oil Immersed Transformer 20kv For Enterprise / Agriculture Images
